HomeProductReversing Camera Kit7″ Monitor HD 12V/24V/32V Reversing Rearview 4PIN CCD Camera Kit Car Truck Caravan

7″ Monitor HD 12V/24V/32V Reversing Rearview 4PIN CCD Camera Kit Car Truck Caravan



 We are selling Heavy Duty Rear View System for Agriculture,Marine,Mining, Transport & Logistics




1. Screen size: 7 inch digital screen

  2.   7″ Digital Monitor

3.Digital 4 Pin Receiver

4.High Resolution 800×480 (HD)

5.High definition 800×480 pixels screen (2400Hx480V)

6. 3 way video inputs optional



Language: Multi-language

Features:Monitor with reverse polarity protect,Sunshade,Keystroke with LED blue light,With light sensor

Wireless Remote Control

Rear-view mirrors allow drivers to view a large portion of the area behind their vehicles. However, trunks and rear decks often limit the view of the road as much as ten to 15 feet behind the vehicle. Sometimes you simply can’t see these things in your conventional rearview mirror.  The rear view cameras feature is an invaluable piece of technology that assists drivers in several ways. The best backup cameras eliminate dangerous blind spots. This makes backing out of the driveway much safer Rear-view cameras, also known as “reversing cameras” or “backup cameras,” resolve this problem. These cameras enable drivers to see objects and people directly behind their vehicles. Rear view cameras make parking, driving and backing up a safer experience for everyone. If you are in the market for this type of product, we highly recommend that you purchase one of the fine products we have researched and reviewed.

l    7” Screen Digital Monitor System

l      Heavy duty trailer cable suzy coil 4PIN Connectors truck caravan 3 AV inputs

l      3 Channel Video Input

l      Those cameras can be used for side view cameras, also can be used for rear view cameras

l      Aluminum shell cameras, IP69K waterproof and 10G Vibration



eBay Image Hosting at www.auctiva.com

eBay Image Hosting at www.auctiva.com

1. Sensor              >            Sharp 1/4” CCD Image Sensor

                         2.  TV System       >                     PAL (AU)                                        NTSC

                         3.  Effective Pixels     >          512 (H) x 582 Pixels                512 x 492 Pixels

    4.  Resolution          >                                            480 TV Line

  5. Sync System        >                                                 Internal

 6. Sensing  System        >                                   2.1 Interface

                           10. Minimum illumination      >                    0.2 Lux/F  1.8 (0 Lux With LED ON)

11. IR Switch State      >                                 <10 Lux CDS ON

12. IR Switch Control      >                   CDS Automatic Control

  13. S/N Ratio     >                                              More Then 48db

 14. Video Output       >                                       1.0 Vp-p,75ohm

                    15. Electronic Shutter Time    >                          Auto  PAL :1/60-1/15000 sec

                    16.  Operation Temperature   >                          -20°C ~ 75˚C ( RH 95% Max)

             17. Storage Temperature      >                      -30°C ~ 85˚C ( RH 95% Max)

      18. Lens     >                                                              2.8mm/120deg

       19. Gain Control      >                                                        Automatic

      20. White Balance       >                                                     Automatic

    21. Current Consumption       >                      No more then 300 mA

        22. Power Supply      >                                                           12V/24V

        23. Function        >                                                 With Night Vision

        24. Waterproof      >                                                           IP 67- IP 68

           25. Weight       >                                                                             300g

                                        26. Dimension   >                            77mm (W)  x  55mm (D)  x  90mm (H)


        1 x 7 Inch 3CH  New Design Monitor

1 x Power Cord

1x Remote Control

1x User Manual

1 x Mount Bracket (screws and nut)

1x  4 Pin Camera

     1x 10m 4 Pin Cable

Installation  available in Melbourne Wide Plz Contact us for a Quote
