7″ LCD MONITOR REVERSING CAMERA REAR VIEW 4 PIN KIT 124V 24V 36V TRUCK,CARAVAN

$1,189.98



814544651_o725531126_o

Description

7 INCH DIGITAL QUAD SCREEN 4 CH MONITOR

We are selling Heavy Duty Rear View System for Agriculture,Marine,Mining, Transport & Logistics

 $_57 edited

MONITOR

  1. 7″ Digital Quad Screen 4CH Heavy Duty Monitor
  2. 7 inch digital screen
  3. Digital 4 Pin Monitor
  4. High Resolution 800 x 480 (HD)
  5. 4 way video inputs optional
  6. DC12V~36V
  7. OSD MENU
  8. Multi-language
  9. Features – Monitor with reverse polarity protect, Sunshade, Keystroke with LED blue light; With light sensor

CAMERA

1. Sensor              >            Sharp 1/4” CCD Image Sensor

                         2.  TV System       >                     PAL (AU)                                        NTSC

                         3.  Effective Pixels     >          512 (H) x 582 Pixels                512 x 492 Pixels

    4.  Resolution          >                                            480 TV Line

  5. Sync System        >                                                 Internal

 6. Sensing  System        >                                   2.1 Interface

                           7Minimum illumination      >                    0.2 Lux/F  1.8 (0 Lux With LED ON)

8. IR Switch State      >                                 <10 Lux CDS ON

9. IR Switch Control      >                   CDS Automatic Control

  10. S/N Ratio     >                                              More Then 48db

 11. Video Output       >                                       1.0 Vp-p,75ohm

                    12. Electronic Shutter Time    >                          Auto  PAL :1/60-1/15000 sec

                    13.  Operation Temperature   >                          -20°C ~ 75˚C ( RH 95% Max)

             14. Storage Temperature      >                      -30°C ~ 85˚C ( RH 95% Max)

      15. Lens     >                                                              2.8mm/120deg

       16. Gain Control      >                                                        Automatic

      17. White Balance       >                                                     Automatic

    18. Current Consumption       >                      No more then 300 mA

        19. Power Supply      >                                                           12V/24V

        20. Function        >                                                 With Night Vision

        21. Waterproof      >                                                           IP 67- IP 68

           22. Weight       >                                                                             300g



Featuring a full colour Heavy Duty steel case colour CCD Camera, suitable for any vehicle, especially Buses and Commercial Trucks where reversing blind spots are a problem, waste management trucks to monitor hopper area, School Buses to monitor back and side passage ways, Animal Transportation to keep an eye on livestock, Camper Vans and Caravans.

Installation  available in Melbourne Wide Plz Contact us for a Quote

PACKAGE INCLUDES:-

1 x 7 Inch 4CH  Digital Split Screen Monitor

1 x Power Cord

1 x Remote Control

1 x User Manual

1 x Mount Bracket (screws and nut)

2 x  Rear View 4 Pin Camera

     3 x  10m 4 Pin Cable

1 x Trailer 1CH Coil Cable
